BendPak MDS-6LP Mid-Rise Open-Center Lift
The BendPak MDS-6LP is a high-performance mid-rise open-center scissor lift, designed for superior accessibility and efficiency. With a 6,000 lb. lifting capacity, longer platforms, and an extended lift point spread, this lift provides a secure and stable lifting experience for a wide variety of vehicle types, including those with longer wheelbases.
Unlike conventional scissor lifts that struggle with low-clearance vehicles, the MDS-6LP features a pivoting kicker mechanism, delivering extra lift force during the first six inches of movement. This ensures smooth and reliable lifting from a fully collapsed position.
This mid-rise lift is perfect for repair shops and garages seeking a compact yet powerful lifting solution. Its removable approach ramps allow for a flush-mount setup, giving more working space around the vehicle when needed.
Key Features & Benefits
- 6,000 lb. Load Capacity – Lifts most cars, SUVs, and light trucks.
- Open-Center Design – Provides easy access to undercar components.
- Extended Lift Point Spread – Safely accommodates long wheelbase vehicles.
- Four Solid Steel-Scissor Support Bars – Among the strongest mid-rise lifts available.
- Dual Master Hydraulic Cylinder – Ensures level, stable lifts with equalizing cylinders.
- Solid-Steel Safety Lock Bars – Engage automatically during ascent for added safety.
- Stainless-Steel Pneumatic Cylinders – Enable simultaneous safety lock release.
- Push-Button Safety Lock Release – No manual handles or bars required.
- Pivoting Kicker Mechanism – Offers extra lift force for low-clearance vehicles.
- Removable Approach Ramps – Converts to flush-mount mode for improved workspace.
- Compact Design – Ideal for garages with limited floor space.
Technical Specifications
| Specification | Measurement / Detail |
|---|---|
| Lifting Height (Min.) | 5 in |
| Lifting Height (Max.) | 35 in |
| Length | 70 in |
| Width | 67 in |
| Load Capacity | 6,000 lbs. |
| Voltage Requirement | 208–240V |
| Air Requirement | Min. 50 psi, 10 CFM at installation |
Why Choose the BendPak MDS-6LP?
The BendPak MDS-6LP is a must-have for professionals and automotive enthusiasts needing a versatile, space-saving mid-rise lift. Its advanced hydraulics, steel construction, and innovative features make it a top performer in its class, delivering reliable, level, and secure lifting across a wide range of vehicles.
Final Thoughts
The BendPak MDS-6LP is an innovative, high-performance lift offering exceptional strength, accessibility, and safety. Whether you’re doing wheel and brake work, undercar inspections, or general maintenance, this lift ensures optimal functionality in a compact footprint.
